Field-proven industrial, railway, and subsea power conversion platforms engineered and manufactured by ABSOPULSE in Ottawa, Canada since 1982.
ABSOPULSE Electronics designs and manufactures an extensive line of industrial and railway grade power conversion products. The standard and semi-custom platforms detailed below represent field-proven topology baselines (15VA to over 10kVA, 50Hz, 60Hz, or 400Hz). Every model can be adapted to exact input rails, output configurations, mechanical footprints, ingress protection (up to IP66), and extreme ambient temperature ranges (-40°C to +70°C). All designs are engineered in-house at our 80,000 sq. ft. Ottawa facility under strict ISO/EMC/IEC quality controls.
Single-phase output pure sine wave inverters featuring high efficiency, low THD (<3%), microprocessor control, heavy component derating, and robust filtering for severe electrical and mechanical operating environments.
| Model / Series | Output Power | Input Voltage | Output Voltage | Dimensions (W x H x L) | Key Technical Features |
|---|---|---|---|---|---|
CSI 30-D1-IP66
|
30VA | 12V, 24V, 36V, 48V, 125Vdc | 115Vac or 230Vac | 120 x 84 x 267 mm (4.7" x 3.3" x 10.5") |
IP66 waterproof die-cast aluminum enclosure, fully ruggedized, conformal coated internal board. |
CSI 30-24-D1 CCTV
|
30VA | 12V, 24V, 36V, 48V, 125Vdc | 24Vac (50Hz / 60Hz) | 120 x 84 x 267 mm (4.7" x 3.3" x 10.5") |
IP66 sealed for outdoor security, surveillance, and CCTV infrastructure in severe industrial sites. |
CSI 50-F1
|
50VA | 12V, 24V, 36V, 48V, 125Vdc | 115Vac or 230Vac | 113 x 51 x 198 mm (4.45" x 2" x 7.8") |
Ultra-compact, low profile chassis, filtered input/output, convection cooled options. |
|
CSI 100-D1 IP66
|
100VA | 24V, 36V, 48V, 125Vdc | 115Vac or 230Vac | 120 x 84 x 267 mm (4.7" x 3.3" x 10.5") |
Fully encapsulated interior, immune to sand, oil, metallic dust, water jets, and corrosive air. |
CSI 100-3W-F1
|
100VA | 20–60Vdc wide-range (24V/36V/48V) | 115Vac or 230Vac | 113 x 51 x 198 mm (4.45" x 2" x 7.8") |
Multi-voltage input rail compatibility in a single compact chassis. Ideal for utility sub-stations. |
CSI 200-F3
|
200VA | 24V, 36V, 48V, 125Vdc | 115Vac or 230Vac | 132 x 62 x 290 mm (5.2" x 2.43" x 11.4") |
Convection cooled, field-proven topology targeting operating lifespan of up to 30 years. |
|
CSI 300-FX
|
300VA | 24V, 36V, 48V, 110V, 125Vdc | 115Vac or 230Vac | 153 x 67 x 351 mm (6" x 2.63" x 13.8") |
Low profile, high efficiency switch-mode design, clean sine wave output with minimal harmonic distortion. |
|
CSI 500-F21
|
500VA | 24V, 36V, 48V, 125Vdc | 115Vac or 230Vac | 254 x 65.5 x 350.5 mm (10" x 2.58" x 13.8") |
Convection cooling via external baseplate fins, low noise output, continuous rated operation. |
|
CSI 1K-F31
|
1000VA | 24V, 36V, 48V, 125V, 250Vdc | 115Vac or 230Vac | 483 x 67 x 355 mm (19" x 2.64" x 14") |
1U/2U low profile 19" rack-mountable or chassis-mountable build, reliable forced-air or convection option. |
|
CSI 1K-F31-HSA
|
1000VA | 36V, 48V, 72V, 96V, 110Vdc | 115Vac or 230Vac | 572 x 150 x 356 mm (22.5" x 5.9" x 14") |
Fanless pure convection cooling via large heatsink assembly fins for dust-heavy processing environments. |
Engineered to accept high DC bus voltages (up to 800Vdc), ideal for electric vehicle traction systems, hydro-electric sub-stations, solar power distribution, and heavy industrial cranes.
| Model / Series | Output Power | Input Voltage Range | Output Voltage | Dimensions (W x H x L) | Key Technical Features |
|---|---|---|---|---|---|
|
CSH 300-F6
|
300VA | 600Vdc nom. (450–800Vdc) | 115Vac or 230Vac | 210 x 65 x 349 mm (8.25" x 2.55" x 13.75") |
High isolation input design, wide DC operating window, full input surge protection. |
|
CSH 500-F6
|
500VA | 600Vdc nom. (450–800Vdc) | 115Vac or 230Vac | 210 x 65 x 349 mm (8.25" x 2.55" x 13.75") |
Robust power semiconductor derating, heavy-duty chassis mount, comprehensive electronic protections. |
|
CSH-2K-3U7
|
2000VA | 250Vdc nom. (230–600Vdc) | 115Vac or 230Vac | 132 x 432 x 382 mm (5.2" x 17" x 15") |
Specially developed for overhead industrial cranes, port equipment, and harsh DC rail feeds. |
Continuous-duty 3-phase AC output power systems supplying pure 208V, 380V, 400V, or 600Vrms (L-L) at 50Hz, 60Hz, or 400Hz for heavy motor drives, military electronics, subsea pumps, and factory automation.
| Model / Series | Output Power | Input Voltage | 3-Phase Output Voltage | Dimensions (W x H x L) | Key Technical Features |
|---|---|---|---|---|---|
|
CTP 300-F7
|
300VA | 24V, 48V, 110V, 125Vdc | 208Vac or 380Vac (3-Phase) | 254 x 73 x 350.5 mm (10" x 2.87" x 13.8") |
Conduction/convection cooled low-profile build, balanced phase regulation, phase sequence protection. |
|
CTP 1000-F7W
|
1000VA | 48V, 110V, 125Vdc | 208Vac or 380Vac (3-Phase) | 280 x 73 x 350.5 mm (11" x 2.87" x 13.8") |
High power density, internal cooling fans, tight voltage and frequency stability under unbalanced loads. |
|
CTP 3K (6U)
|
3000VA | 24V, 36V, 48V, 125V, 250Vdc | 208V, 380V, 400Vac (3-Phase) | 264 x 483 x 386 mm (6U 19" Rack or Chassis) |
Modular architecture built from rugged internal blocks. Microprocessor-controlled digital synthesis. |
|
CTP 6K-48/600-2X3U7
|
6000VA | 48Vdc (42–56V) | 600Vrms (L-L) 3-Phase 60Hz | 267 x 483 x 382 mm (6U 19" Rack or Chassis) |
Delivers 600Vrms high-voltage 3-phase output directly to heavy machinery without external step-up transformers. |
|
CTP 10K-3X3U7
|
10000VA | 48V, 125V, 250Vdc | 380Vac or 400Vac (3-Phase) | Modular Rack / Chassis (Custom Configuration) |
Industrial multi-kilowatt 3-phase conversion platform, redundant thermal protection, remote alarm signals. |
Precision frequency transformation (e.g., 50Hz to 60Hz, 60Hz to 400Hz, or variable AC output) with complete galvanic isolation between primary AC grids and load circuits. Active PFC options available.
| Model / Series | Output Power | Input AC Range | Output AC Voltage & Freq. | Topology / Conversion Type | Key Technical Features |
|---|---|---|---|---|---|
| FC 100-F2 | 100W | Universal 95–264Vac or 120–350Vdc | 115Vac or 230Vac (50/60/400Hz) | 1-Phase AC to 1-Phase AC | Compact chassis, universal AC input, clean sine wave synthesis for avionics testing and lab gear. |
| FCP 300-FX | 300W | 115Vac / 230Vac (PFC input) | 115Vac or 230Vac (50/60/400Hz) | 1-Phase AC to 1-Phase AC | Active Power Factor Correction (PFC > 0.97), low input harmonic distortion, conduction cooled option. |
| FCP 1K-F7W | 1000W | Universal 95–264Vac (Active PFC) | Split phase 2x115Vac or 230V/400V | 1-Phase AC to Split Phase AC | Split-phase output capability, active PFC front-end, heavy-duty filtering for shipboard systems. |
| FC 2KP-EW/A | 2000W | 230Vac (180–270Vac window) | 120Vac or 230Vac (Regulated) | Generator Voltage Stabilizer | Fully encapsulated internal modules. Designed to condition unstable generator AC feeds in remote mines. |
| FTP 1K5-3U7 | 1500W | 115Vac / 230Vac or Universal PFC | 208V, 380V, 400V 3-Phase AC | 1-Phase AC to 3-Phase AC | Converts single-phase utility voltage into clean 3-phase AC power for industrial motor machinery. |
| FTT 3K-6U | 3000W | 208V / 380V / 400V 3-Phase AC | 208V / 380V / 400V 3-Phase AC | 3-Phase AC to 3-Phase AC | Complete 3-phase isolation and frequency shift (e.g. 50Hz to 60Hz or 400Hz) for aerospace ground support. |
Specially engineered for rolling stock, locomotives, trackside signaling, and transit infrastructure. Built to withstand extreme shock, vibration, thermal cycling, and wide input fluctuations matching RIA12, EN50155, and EN45545 standards.
| Model / Series | Output Power | Railway Input Rail (Nominal) | Output AC Voltage | Enclosure / Protection | Compliance & Build Standard |
|---|---|---|---|---|---|
| RSI 30-D1-IP66 | 30VA | 24V, 48V, 72V, 96V, 110Vdc | 115Vac or 230Vac | IP66 Die-Cast Box | EN50155, IEC 61373 shock/vibration, fully potted modules for trackside signals. |
| RSI 300-D3-IP66 | 300VA | 48V, 72V, 96V, 110Vdc | 115Vac or 230Vac | IP66 Sealed Flange Mount | Complete immunity to washdown, dust, flying ballast, and environmental contaminants on railcars. |
| RSI 1K-HSA-F31 | 1000VA | 36V, 48V, 72V, 96V, 110Vdc | 115Vac or 230Vac | F31 Heatsink Assembly | Convection cooled via external heat-sink fins. No fans to maintain, targeting 30-year railway life. |
| CTP 300R-F7 | 300VA (3-Phase) | 24V, 36V, 48V, 72V, 96V, 110Vdc | 208Vrms 3-Phase (60/400Hz) | Rugged Chassis Baseplate | Onboard rolling stock 3-phase inverter driving specialized HVAC blowers, pumps, and electronics. |
Elimination of optocouplers, field-proven topologies, conservative electronic component derating, and opto-isolated feedback loops ensure up to 30-year design life targets.
Next-generation SiC switching semiconductors maximize power density, lower thermal dissipation, and deliver exceptional electrical efficiency even at elevated ambient temperatures.
From pure convection baseplate cooling to die-cast IP66 enclosures, units resist water jets, salt spray, conductive dust, sand, fog, oil, and severe mechanical shock/vibration.
Our Ottawa engineering team customizes input/output voltages, mechanical housings, pinouts, and thermal management options directly for original equipment manufacturers (OEMs), utilities, and defense contractors globally.
